Professional Design Inkjet Printer Ink - Rainbow Nano 7 A2+ digital uv printer – Rainbow

Short Description:


Product Overview

Product Tags

Related Video

Feedback (2)

We retain bettering and perfecting our merchandise and service. At the same time, we do the job actively to do research and improvement for Uv Led Printer Phone Case, A1 Uv Flatbed Printer, Ripples Coffee Printer, We can do your customized order to meet your own satisfactory! Our company sets up several departments, including production department, sales department, quality control department and sevice center, etc.
Professional Design Inkjet Printer Ink - Rainbow Nano 7 A2+ digital uv printer – Rainbow Detail:

catalog-uv-printer-Nano7

 Specs of Rainbow Nano 7 UV flatbed printer

Name Rainbow Nano 7 A2+ digital uv printer Working Environment 10 ~ 35 ℃ HR40-60%
Machine Type Automatic Flatbed UV digital printer Printer Head Double Printer Heads
Features · The UV light source can be adjusted RIP Software Maintop 6.0 or PhotoPrint DX 12
· Auto height measurement Operation System All Microsoft Windows system
. Power auto flash clean Interface USB2.0/3.0 Port
·Print on most material directly Languages English/Chinese
· Ideal for industrial bulk production with high printing speed Ink Type UV LED curing ink
· Finished products is Water proof, UV proof, and Scratch proof Ink System CISS Built Inside With Ink Bottle
· Finished product is suitable for outdoor use Ink Supply 500ml/Bottle
· Max printing Size: 50*70cm Height Adjustment Automatic with Sensor.
· With fixed angel Driving Power 110 V/ 220 V.
· The printing machine can print white color and 3D emboss effect Power Consumption 500W
Materials to Print · Metal, Plastic, glass, wood,Acrylic, Ceramics,PVC,Steel board,Paper, Media Feeding System Auto/Manual
·TPU, Leather, Canvas, etc Ink Consumption 9-15ml/SQM.
UV Curing System Water Cooling Print Quality 720×720dpi/720*1080DPI(6/8/12/16pass)
Printing Method Drop-on-demand Piezo Electric Inkjet Machine Dimension 106x104x65CM
Printing Direction Smart Bi-directional Printing Mode Packing Size 116x114x85CM
Printing Speed About 4 minutes for 720*720dpi, 500mm*700mm size Machine Net Weight 55kg
Max. Print Gap 16cm Gross.Weight 77kg
Power Requirement 50/60HZ 220V(±10%)<5A Packing Way Wooden Case

Nano 7 uses 4 pieces Hi-win brand accurate linear guide rail with long lifespan.

Nano 7 uses in Hi-win brand linear guide rail ensured the smooth and silence working of the print head up and down, flatbed move forth and back.

Nano 7 equipped with double print head + CMYKW all colors printing.

Double print head with all colors quick printing.

Ink stack adopts the precise sliding and leaning ink stack to precisely and automatically clean, moisturize and wipe the ink,which is convenient to use and effectively prolong the service life of the nozzle.

360° rotary bottles printing + mug with handle printing.

Nano 7 equipped with two kinds of rotary devices for any bottles printing, the allowed diameter is from 1cm to 12cm, all tiny cylinder can be printed.

3D embossed effect.

The uv printer can print with 3D effect and texture effect.

Good quality LED display for convenient use, industrial UV curable light make sure ink dry instant after printing.

sample-UV-printing-Nano7
UV-printer-packaging-steps-Nano7
4060-UV-Inkjet-Printer-10
4060-UV-Inkjet-Printer-11
4060-UV-Inkjet-Printer-12
4060-UV-Inkjet-Printer-14

Q1:What materials can UV printer print?
A:UV printer can print almost all kinds materials, such as phone case, leather, wood,plastic, acrylic, pen, golf ball, metal, ceramic, glass, textile and fabrics etc.

Q2:Can UV printer print embossing 3D effect?
A:Yes, it can print embossing 3D effect, contact us for more information and printing videos

Q3:Can A3 uv flatbed printer do rotary bottle and mug printing?
A:Yes, both bottle and mug with handle can be printed with the help of rotary printing device.

Q4:Does printing materials must be sprayed a pre-coating?
A:Some material need pre-coating, such as metal, glass, acrylic for make the color anti-scratch.

Q5:How can we start to use the printer?
A:We will send the detailed manual and teaching videos with the package of the printer before use the machine, please read the manual and watch the teaching video and operate strictly as the instructions, and if any question unclarified, our technical support online by teamviewer and video call will be help.

Q6:What about the warranty?
A:We have 13 months warranty and lifelong technical support, not include consumables like print head and ink dampers.

Q7:What's the printing cost?
A:Usually,1 square meter need cost about $1 printing cost with our good quality ink.

Q8:Where can I buy the spare parts and inks?
A:All spare parts and ink will be available from us during the whole lifespan of printer, or you can buy at local.

Q9:What about maintenance of the printer?
A:The printer has auto-cleaning and auto keep wet system, each time before power off machine, please do a normal cleaning so that keep print head wet. If you don't use the printer more than 1 week, it’s better to power on machine 3 days later to do a test and auto clean.
